Easy Maintenance
- The solenoid in a single piece with plunger and built-in spring-loaded for easy assistance. Prevents loss of parts during maintenance in the field.
- The flow control regulates the flow of water according to need.
- The exhaust device of the internal manual be performed by turning a quarter turn of the solenoid operates the valve without allowing water to flood the valve box. Allows the adjustment of the pressure regulator without having to turn on the valve by the programmer.
- The exhaust device to the atmosphere, allows cleaning of the system by material in suspension. Recommended at start-up and after repairs of the system.
- Solenoid with convenient handwheel.

Versatility
- Configuration in-line
- Wide range of operating pressures. Ability to operate at low flow rates for a wide range of applications.
- Pressure regulators (PRS-Dial) adjustable from 1.0 to 6.9 bar that can be coupled to the valve in the field (to be ordered separately)
- Compatible with the solenoids bistable Rain Bird, for use with the programmers, battery-powered Rain Bird. Important: do not use the latching solenoid with operating pressures over 10 bar.
- Compatible with the Systems Decoder MDC RainBird.

Reliability
- The body and the cover, with nylon fiber, enriched with glass fibre.
- Nylon filter self-cleaning in the series PEB.
- Cleaning device in the models PESB that keeps it clean the strainer in stainless steel every time you open or close the valve.

SPECIFICATIONS
- Flow rate: 0.06 to 45,0 m3/h
- Pressure: 1.4 to 13.8 bar (23°C)
- Temperature: up to 66° C

SPECIFICATIONS ELECTRICAL
- Solenoid: 24 Vac-50Hz
- Inrush current: 0,14 A (9,9 VA)
- Power consumption: 0,23 A (5,5 VA)
