3SRm 5/16 - 1 HP single-phase submersible electric pump
Flow rate up to 120 l/min (7.2 m³/h). Head up to 48 m. 0.75 Kw (1 HP) motor.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | Monday 26 October - Tuesday 27 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | Monday 26 October - Tuesday 27 October |
 | DHL - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust the products to him. | Monday 26 October - Tuesday 27 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Friday 23 October |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
Monday 26 October - Tuesday 27 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
Monday 26 October - Tuesday 27 October
Carrier: DHL - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust the products to him.
Estimated delivery:
Monday 26 October - Tuesday 27 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Friday 23 October
The Pedrollo 3SRm 5/16 submersible electric pump has a flow rate that can vary from 15 to 120 litres per minute with a head from 16 to 48 metres.
The key features of this pump are its efficient operation and its construction, which allows for comfortable use.
The 3SRm 5/16 pump saves water and consequently energy. It can pump water with sand content up to 150 grams per cubic meter.
Its construction and lightweight make installation convenient and simple. It can be installed in wells up to 100 meters deep with a suitable power cable. It has an IP68 water and dust protection rating.
Recommended for domestic and civil applications. The 3SRm 5/16 is suitable for a variety of applications, including domestic water supply, irrigation, and water systems for small communities.
The pump motor is made with rewindable oil bath technique.
It must be powered by a single-phase voltage, has a horsepower of 1 HP and the temperature of the liquid to be pumped reaches up to +35 degrees centigrade.
The 3SRm 5/16 benefits from a solid construction, it is made of AISI 304 stainless steel which makes it robust and resistant.
- Jobs
- water supply, pressurization systems, irrigation
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 0.75
- Power (HP)
- 1
- Absorption at 230V (A)
- 6, 6
- Pump body
- AISI 304 stainless steel
- Impeller
- Noryl
- Number of impellers
- 16
- Crankshaft
- AISI 304 stainless steel
- Check valve
- No
- Minimum flow rate (l./min.)
- 15, 15
- Max. flow rate (l./min.)
- 120, 120
- Min. head (m.)
- 15, 15
- Max. head (m.)
- 45, 45
- Max. liquid temperature (°C)
- +35°C, +35°C
- Motor voltage
- 230 V
- Degree of protection
- IP 68
- Delivery mouth
- 1"
- Height (cm)
- 130.9, 130.9
- Weight (Kg)
- 13.1, 13.1
- Diameter (cm)
- 7.6, 7.6
- Warranty (years)
- 2
Use and formulation of products
- Jobs
- water supply, pressurization systems, irrigation
Engine and mechanical performance
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 0.75
- Power (HP)
- 1
- Absorption at 230V (A)
- 6
Pump components and construction
- Pump body
- AISI 304 stainless steel
- Impeller
- Noryl
- Number of impellers
- 16
- Crankshaft
- AISI 304 stainless steel
- Check valve
- No
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 15
- Max. flow rate (l./min.)
- 120
- Min. head (m.)
- 15
- Max. head (m.)
- 45
Liquids and pumping conditions
- Max. liquid temperature (°C)
- +35°C
Power supply and electrical parameters
- Motor voltage
- 230 V
Safety and protection
- Degree of protection
- IP 68
Installation and connections
- Delivery mouth
- 1"
Dimensions and weight
- Height (cm)
- 130.9
- Weight (Kg)
- 13.1
- Diameter (cm)
- 7.6
Packaging, maintenance, and warranty
- Warranty (years)
- 2
Bearings
| Pump bearing - fixed part | Anti-friction polymer |
| Pump bearing - rotating part | Sintered AISI 316 steel with ceramic coating |
Tree holding
Materials
| 1.3 - Delivery body | Stainless steel EN 1.4301 (AISI 304) |
| 3.0 - Impeller | POM acetal resin |
| 4.0 - Pump shaft | Stainless steel EN 1.4301 (AISI 304) |
| 4.2 - Towing joint | Stainless steel EN 1.4404 (AISI 316L) |
| 5.1 - Diffuser | Reinforced technopolymer |
| 5.3 - Diaphragm/Diffuser Cover | Reinforced technopolymer |
| 7.0 - Lantern | Stainless steel EN 1.4301 (AISI 304) |
| 7.1 - Check Valve | Stainless steel EN 1.4301 (AISI 304) |
| 7.2 - Pump shirt | Stainless steel EN 1.4301 (AISI 304) |
| 7.3 - Cable cover | Stainless steel EN 1.4301 (AISI 304) |
| 8.0 - Suction Grid/Filter | Stainless steel EN 1.4301 (AISI 304) |
