Dm 10 (5m) - 1 HP single-phase clear water pump
Flow rate up to 300 l/min (18 m³/h). Head up to 16 m. 0.75 kW (1 HP) motor. 5 m cable with Schuko plug.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | Thursday 22 October - Friday 23 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | Thursday 22 October - Friday 23 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Thursday 22 October |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
Thursday 22 October - Friday 23 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
Thursday 22 October - Friday 23 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Thursday 22 October
The Dm 10 submersible electric pump from the Pedrollo D series is recommended for domestic and civil installations.
Suitable for draining clear or slightly dirty water with the presence of suspended solids of up to 10 millimetres.
It is particularly suitable for activities such as draining flooded areas such as basements and garages, for emptying swimming pools and tanks and for disposing of non-sewage waste water.
The Dm 10 stands out for its reliability, particularly in fixed installations with automatic operation.
The supplied cable is 5 meters long.
- Jobs
- drainage, drying up
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 0.75
- Power (HP)
- 1
- Absorption at 230V (A)
- 4.7
- Capacitor
- 20 µF 450 VL
- Pump body
- Cast iron
- Impeller
- Technopolymer
- Number of impellers
- 1
- Crankshaft
- AISI 431 stainless steel
- Check valve
- No
- Minimum flow rate (l./min.)
- 25
- Max. flow rate (l./min.)
- 300
- Min. head (m.)
- 3
- Max. head (m.)
- 16
- Max. liquid temperature (°C)
- +40°C
- Cable length (m.)
- 5
- Degree of protection
- IP 68
- Delivery mouth
- 1" 1/2
- Height (cm)
- 34.4
- Weight (Kg)
- 12.9
- Warranty (years)
- 2
Use and formulation of products
- Jobs
- drainage, drying up
Engine and mechanical performance
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 0.75
- Power (HP)
- 1
- Absorption at 230V (A)
- 4.7
- Capacitor
- 20 µF 450 VL
Pump components and construction
- Pump body
- Cast iron
- Impeller
- Technopolymer
- Number of impellers
- 1
- Crankshaft
- AISI 431 stainless steel
- Check valve
- No
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 25
- Max. flow rate (l./min.)
- 300
- Min. head (m.)
- 3
- Max. head (m.)
- 16
Liquids and pumping conditions
- Max. liquid temperature (°C)
- +40°C
Power supply and electrical parameters
- Cable length (m.)
- 5
Safety and protection
- Degree of protection
- IP 68
Installation and connections
- Delivery mouth
- 1" 1/2
Dimensions and weight
- Height (cm)
- 34.4
- Weight (Kg)
- 12.9
Packaging, maintenance, and warranty
- Warranty (years)
- 2
|
|
|
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bearings
| Pump side motor bearing | 6203 ZZ |
| Opposite side engine bearing | 6203 ZZ |
Tree holding
| Type of seal | Double mechanical seal in oil chamber |
| LM diameter | 14 |
| LM fixed ring | Silicon carbide |
| LM rotating ring | Graphite |
| LM elastomer | NBR |
| Shrinkage DN1=450 DN2=350 | MG1-14D SIC |
| LP diameter | 14 |
| LP fixed ring | Silicon carbide |
| LP rotating ring | Silicon carbide |
| LP elastomer | NBR |
Materials
| 1.0 - Pump body | Cast iron GJL 200 EN 1561 |
| 2.2 - Suction cover | Stainless steel EN 1.4301 (AISI 304) |
| 3.0 - Impeller | Reinforced technopolymer |
| 4.0 - Pump shaft | Stainless steel EN 1.4057 (AISI 431) |
| 6.0 - Motor holder | Stainless steel EN 1.4301 (AISI 304) |
| 6.1 - Engine cover | Stainless steel EN 1.4301 (AISI 304) |
| 7.0 - Lantern | Stainless steel EN 1.4301 (AISI 304) |
| 8.0 - Suction Grid/Filter | Stainless steel EN 1.4301 (AISI 304) |
Compare with Similar Products
 Dm 10 (5m) - 1 HP single-phase clear water pumpThis product Flow rate up to 300 l/min (18 m³/h). Head up to 16 m. 0.75 kW (1 HP) motor. 5 m cable with Schuko plug. |  Dm 8 (5m) - 0.75 HP single-phase clear water pump Flow rate up to 250 l/min (15 m³/h). Head up to 13 m. 0.55 kW (0.75 HP) motor. 5-meter cable with Schuko plug. |  Dm 20 (5m) - 1 HP single-phase clear water pump Flow rate up to 250 l/min (15 m³/h). Head up to 20 m. 0.75 kW (1 HP) motor. 5 m cable with Schuko plug. |  Dm 30 - 1.5 HP single-phase electric pump for clear water Flow rate up to 275 l/min (16.5 m³/h). Head up to 26 m. 1.1 kW (1.5 HP) motor. | |
|---|---|---|---|---|
| Price | Price €464.82 -42% €269.60 | Price €453.84 -42% €263.23 | Price €490.44 -42% €284.46 | Price €617.32 -42% €358.05 |
| Jobs | Jobs drainage, drying up | Jobs drainage, drying up | Jobs drainage, drying up | Jobs drainage, drying up |
| Motor connection | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE |
| Power (Kw) | Power (Kw) 0.75 | Power (Kw) 0.55 | Power (Kw) 0.75 | Power (Kw) -- |
| Power (HP) | Power (HP) 1 | Power (HP) 0.75 | Power (HP) 1 | Power (HP) 1.5 |
| Absorption at 230V (A) | Absorption at 230V (A) 4.7 | Absorption at 230V (A) 3.2 | Absorption at 230V (A) 5.7 | Absorption at 230V (A) 7.2 |
| Capacitor | Capacitor 20 µF 450 VL | Capacitor 20 µF 450 VL | Capacitor 20 µF 450 VL | Capacitor 25 µF 450 VL |
| Pump body | Pump body Cast iron | Pump body Cast iron | Pump body Cast iron | Pump body Cast iron |
| Impeller | Impeller Technopolymer | Impeller Technopolymer | Impeller Technopolymer | Impeller Technopolymer |
| Number of impellers | Number of impellers 1 | Number of impellers 1 | Number of impellers 1 | Number of impellers 1 |
| Crankshaft | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel |
| Check valve | Check valve No | Check valve No | Check valve No | Check valve No |
| Minimum flow rate (l./min.) | Minimum flow rate (l./min.) 25 | Minimum flow rate (l./min.) 25 | Minimum flow rate (l./min.) 25 | Minimum flow rate (l./min.) 25 |
| Max. flow rate (l./min.) | Max. flow rate (l./min.) 300 | Max. flow rate (l./min.) 250 | Max. flow rate (l./min.) 250 | Max. flow rate (l./min.) 275 |
| Min. head (m.) | Min. head (m.) 3 | Min. head (m.) 3 | Min. head (m.) 8 | Min. head (m.) 9 |
| Max. head (m.) | Max. head (m.) 16 | Max. head (m.) 13 | Max. head (m.) 20 | Max. head (m.) 26 |
| Max. liquid temperature (°C) | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C |
| Cable length (m.) | Cable length (m.) 5 | Cable length (m.) 5 | Cable length (m.) 5 | Cable length (m.) 10 |
| Degree of protection | Degree of protection IP 68 | Degree of protection IP 68 | Degree of protection IP 68 | Degree of protection IP 68 |
| Delivery mouth | Delivery mouth 1" 1/2 | Delivery mouth 1" 1/2 | Delivery mouth 1" 1/2 | Delivery mouth 1" 1/2 |
| Height (cm) | Height (cm) 34.4 | Height (cm) 34.4 | Height (cm) 34.4 | Height (cm) 35.5 |
| Weight (Kg) | Weight (Kg) 12.9 | Weight (Kg) 12 | Weight (Kg) 12.9 | Weight (Kg) 15.1 |
| Warranty (years) | Warranty (years) 2 | Warranty (years) 2 | Warranty (years) 2 | Warranty (years) 2 |
