FUTURE JETm 2A-ST - 1.25 HP single-phase self-priming electric pump
Flow rate up to 120 l/min (7.2 m³/h). Head up to 58 m. 1.1 kW (1.25 HP) motor.
The FUTURE JETm 2A-ST self-priming electric pump is recommended for pumping clean water and liquids that are chemically non-aggressive towards the pump's constituent materials. It is designed to draw water even when air is mixed with the pumped liquid.
It has a flow rate that varies from 5 to 120 litres per minute with a head from 13 to 58 metres.
With an internationally registered patent, the FUTURE JET series electric pumps are able to obtain the same pressure as a classic JET but double the flow rate, achieving a reduction in energy consumption of up to 50%.
Due to its reliability and ease of use, it is recommended for domestic use, especially for water distribution in conjunction with small or medium-sized pressure tanks, for irrigation of vegetable gardens and gardens.
Installation must be carried out in well-ventilated, closed areas or in any case protected from the elements.
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 0.90
- Power (HP)
- 1.25
- Absorption at 230V (A)
- 6.6
- Capacitor
- 25 µF 450 VL
- Suction mouth
- 1"
- Delivery mouth
- 1"
- Pump body
- Cast iron
- Impeller
- AISI 304 stainless steel
- Number of impellers
- 1
- Crankshaft
- AISI 431 stainless steel
- Check valve
- No
- Degree of protection
- IP 44
- Minimum flow rate (l./min.)
- 5
- Max. flow rate (l./min.)
- 120
- Min. head (m.)
- 13
- Max. head (m.)
- 58
- Jobs
- water supply, pressurization systems, irrigation
- Max. liquid temperature (°C)
- +40°C
- Height (cm)
- 18.3
- Width (cm)
- 18.2
- Depth (cm)
- 36.7
- Weight (Kg)
- 11.8
- Warranty (years)
- 2
|
|
|
|
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bearings
| Pump side motor bearing | 6203ZZ |
| Opposite side engine bearing | 6203ZZ |
Shaft seal
| Seal type | Single Mechanical Seal |
| Pump side model | AR-14 |
| LP diameter | 14 |
| LP fixed ring | Ceramic |
| Rotating ring LP | Graphite |
| LP elastomer | NBR |
Materials
| 1.0 - Pump Body | Stainless steel EN 1.4301 (AISI 304) |
| 2.1 - Seal holder cover | Stainless steel EN 1.4301 (AISI 304) |
| 3.0 - Impeller | Stainless steel EN 1.4301 (AISI 304) |
| 3.1 - Ejector Group | Reinforced technopolymer |
| 4.0 - Pump shaft | Stainless steel EN 1.4057 (AISI 431) |
| 6.0 - Motor carrier | EN-AB 46100 aluminium |
| 7.0 - Lantern | EN-AB 46100 aluminium |
-
- -5%
€17.96 tax incl. €18.91 -
Reviews (3) - Review moderation
Perfetta buonissima pompa.
The customer has not left any comments.
Il cliente non ha lasciato alcun commento.
Compare with Similar Products
 FUTURE JETm 2A-ST - 1.25 HP single-phase self-priming electric pumpThis product Flow rate up to 120 l/min (7.2 m³/h). Head up to 58 m. 1.1 kW (1.25 HP) motor. |  FUTURE JETm 2A - 1.25 HP single-phase self-priming electric pump Flow rate up to 120 l/min (7.2 m³/h). Head up to 59 m. 0.90 Kw (1.25 HP) motor. | |
|---|---|---|
| Price | Price €356.24 -42% €206.62 | Price €320.86 -42% €186.10 |
| Motor connection | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE |
| Power (Kw) | Power (Kw) 0.90 | Power (Kw) 0.90 |
| Power (HP) | Power (HP) 1.25 | Power (HP) 1.25 |
| Absorption at 230V (A) | Absorption at 230V (A) 6.6 | Absorption at 230V (A) 6.6 |
| Capacitor | Capacitor 25 µF 450 VL | Capacitor 25 µF 450 VL |
| Suction mouth | Suction mouth 1" | Suction mouth 1" |
| Delivery mouth | Delivery mouth 1" | Delivery mouth 1" |
| Pump body | Pump body Cast iron | Pump body Cast iron |
| Impeller | Impeller AISI 304 stainless steel | Impeller AISI 304 stainless steel |
| Number of impellers | Number of impellers 1 | Number of impellers 1 |
| Crankshaft | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel |
| Check valve | Check valve No | Check valve -- |
| Degree of protection | Degree of protection IP 44 | Degree of protection -- |
| Minimum flow rate (l./min.) | Minimum flow rate (l./min.) 5 | Minimum flow rate (l./min.) 5 |
| Max. flow rate (l./min.) | Max. flow rate (l./min.) 120 | Max. flow rate (l./min.) 120 |
| Min. head (m.) | Min. head (m.) 13 | Min. head (m.) 13.7 |
| Max. head (m.) | Max. head (m.) 58 | Max. head (m.) 59 |
| Jobs | Jobs water supply, pressurization systems, irrigation | Jobs water supply, pressurization systems, irrigation |
| Max. liquid temperature (°C) | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C |
| Height (cm) | Height (cm) 18.3 | Height (cm) 17.1 |
| Width (cm) | Width (cm) 18.2 | Width (cm) 15.8 |
| Depth (cm) | Depth (cm) 36.7 | Depth (cm) 35.7 |
| Weight (Kg) | Weight (Kg) 11.8 | Weight (Kg) 9.7 |
| Warranty (years) | Warranty (years) 2 | Warranty (years) 2 |
