TOP 1 - FLOOR (10m) - 0.33 HP clear water drainage pump
Flow rate up to 120 l/min (7.2 m³/h). Head up to 6.5 m. 0.25 kW (0.33 HP) motor. 10-meter cable with Schuko plug.
Telephone support for information before purchasing.
Reinforced packaging to reduce transport damage.
After-sales assistance for product installation.
We supply all spare parts on this product.
Description
The TOP 1 - FLOOR submersible electric pump from the TOP-FLOOR series by Pedrollo is recommended for draining flooded areas up to 2 millimetres from the bottom.
Suitable for draining clear water without abrasive particles.
Suitable for emergency domestic use in small flooded areas and in all situations where maximum drainage levels are required.
The TOP 1 - FLOOR can be installed up to 3 meters below the water level.
Allows the passage of suspended solids up to 2 millimetres in diameter.
Data sheet
- Motor connection
- SINGLE-PHASE
- Power (HP)
- 0.33
- Absorption at 230V (A)
- 1.5
- Capacitor
- 10 µF 450 VL
- Delivery mouth
- 1" 1/4
- Pump body
- Technopolymer
- Impeller
- Noryl
- Number of impellers
- 1
- Crankshaft
- AISI 431 stainless steel
- Check valve
- No
- Degree of protection
- IP 68
- Minimum flow rate (l./min.)
- 20
- Max. flow rate (l./min.)
- 120
- Min. head (m.)
- 2
- Max. head (m.)
- 6.5
- Jobs
- drainage, drying up
- Max. liquid temperature (°C)
- +40°C
- Height (cm)
- 25.7
- Width (cm)
- 15.2
- Weight (Kg)
- 5.1
- Warranty (years)
- 2
TOP models and performances - FLOOR
|
|
|
|
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction data of the TOP series
Bearings
| Pump side motor bearing | 6201 ZZ |
| Opposite side engine bearing | 6201 ZZ |
Tree holding
| Type of seal | Double Seal: Mechanical and Lip with oil chamber |
| Engine side model | Lip seal |
| LM diameter | 12 |
| LM elastomer | NBR |
| Shrinkage DN1=450 DN2=350 | STA-12R |
| LP diameter | 12 |
| LP fixed ring | Ceramic |
| LP rotating ring | Graphite |
| LP elastomer | NBR |
Materials
| 1.0 - Pump body | Reinforced technopolymer |
| 2.2 - Suction cover | Stainless steel EN 1.4301 (AISI 304) |
| 3.0 - Impeller | Reinforced technopolymer |
| 4.0 - Pump shaft | Stainless steel EN 1.4057 (AISI 431) |
| 5.1 - Diffuser | Reinforced technopolymer |
| 6.0 - Motor holder | Stainless steel EN 1.4301 (AISI 304) |
| 6.1 - Engine cover | Stainless steel EN 1.4301 (AISI 304) |
| 8.0 - Suction Grid/Filter | Reinforced technopolymer |
