4HR10/7 - HYD - 250 litre submersible pump
HYDRAULIC PART. WITHOUT MOTOR.
Flow rate up to 250 l/min (1.8 m³/h). Head up to 40 metres.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | Wednesday 21 October - Thursday 22 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | Wednesday 21 October - Thursday 22 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | tomorrow |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
Wednesday 21 October - Thursday 22 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
Wednesday 21 October - Thursday 22 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
tomorrow
The Pedrollo 4HR 10/7 HYD pump consists of only the impeller part, without the motor.
The 4HR 10/7 HYD can be fitted to any 1.5 HP engine.
Recommended for pumping clean water with sand content not exceeding 150 grams per cubic meter.
It has a flow rate that varies from 50 to 250 litres per minute with a head of 10 to 40 metres.
Due to their high performance and reliability, they are suitable for use in domestic, civil and industrial fields, for the distribution of water in combination with pressure tanks, for irrigation, for washing systems, for pressure raising and for fire-fighting systems.
Original spare part for 4HR10/7.
- Power (HP)
- 1
- Pump body
- AISI 304 stainless steel
- Impeller
- Delrin
- Number of impellers
- 7
- Pump shaft
- AISI 304 stainless steel
- Minimum flow rate (l./min.)
- 50
- Max. flow rate (l./min.)
- 250
- Min. head (m.)
- 10
- Max. head (m.)
- 40
- Delivery mouth
- 2"
- Height (cm)
- 66
- External diameter (cm)
- 10
- Warranty (years)
- 2
Engine and mechanical performance
- Power (HP)
- 1
Pump components and construction
- Pump body
- AISI 304 stainless steel
- Impeller
- Delrin
- Number of impellers
- 7
- Pump shaft
- AISI 304 stainless steel
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 50
- Max. flow rate (l./min.)
- 250
- Min. head (m.)
- 10
- Max. head (m.)
- 40
Installation and connections
- Delivery mouth
- 2"
Dimensions and weight
- Height (cm)
- 66
- External diameter (cm)
- 10
Packaging, maintenance, and warranty
- Warranty (years)
- 2
