4HR18/6 - HYD - 420 litre submersible pump
HYDRAULIC PART. WITHOUT MOTOR.
Flow rate up to 420 l/min (1.8 m³/h). Head up to 35 metres.
-
Telephone support for information before purchasing.
-
Reinforced packaging to reduce transport damage.
-
After-sales assistance for product installation.
-
Original replacement
The Pedrollo 4HR 18/6 HYD pump consists of only the impeller part, without the motor.
The 4HR 18/6 HYD can be fitted to any 2 HP engine.
Recommended for pumping clean water with sand content not exceeding 150 grams per cubic meter.
It has a flow rate that varies from 50 to 420 litres per minute with a head of 7 to 35 metres.
Due to their high performance and reliability, they are suitable for use in domestic, civil and industrial fields, for the distribution of water in combination with pressure tanks, for irrigation, for washing systems, for pressure raising and for fire-fighting systems.
Original spare part for 4HR18/6.
- Power (HP)
- 2
- Pump body
- AISI 304 stainless steel
- Impeller
- AISI 304 stainless steel
- Number of impellers
- 6
- Pump shaft
- AISI 304 stainless steel
- Minimum flow rate (l./min.)
- 50
- Max. flow rate (l./min.)
- 420
- Min. head (m.)
- 7
- Max. head (m.)
- 35
- Delivery mouth
- 2"
- Height (cm)
- 58.7
- Weight (Kg)
- 10.2
- Warranty (years)
- 2
Engine and mechanical performance
- Power (HP)
- 2
Pump components and construction
- Pump body
- AISI 304 stainless steel
- Impeller
- AISI 304 stainless steel
- Number of impellers
- 6
- Pump shaft
- AISI 304 stainless steel
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 50
- Max. flow rate (l./min.)
- 420
- Min. head (m.)
- 7
- Max. head (m.)
- 35
Installation and connections
- Delivery mouth
- 2"
Dimensions and weight
- Height (cm)
- 58.7
- Weight (Kg)
- 10.2
Packaging, maintenance, and warranty
- Warranty (years)
- 2
