6HR 54/13 - HYD - 1200 litre submersible pump

HYDRAULIC PART. WITHOUT MOTOR.

Flow rate up to 1200 l/min (72 m³/h). Head up to 148 metres.

  • Telephone support for information before purchasing.
  • Reinforced packaging to reduce transport damage.
  • After-sales assistance for product installation.
  • Original replacement
Buy it with
  • 6HR 54/13 - HYD - 1200 litre submersible pump
  • +
  • 6PD/30 - Three-phase 6" 30 HP rewindable motor
  • +
  • EASYPRESS-BLU - Electronic pressure regulator
  • €4,036.74-10 %
    Total price: €3,633.07

Related Products

Compare with Similar Products

6HR 54/13 - HYD - 1200 litre submersible pump

6HR 54/13 - HYD - 1200 litre submersible pump

This product

HYDRAULIC PART. WITHOUT MOTOR.

Flow rate up to 1200 l/min (72 m³/h). Head up to 148 metres.

6HR 54/11 - HYD - 1200 litre submersible pump

6HR 54/11 - HYD - 1200 litre submersible pump

Quick View

HYDRAULIC PART. WITHOUT MOTOR.

Flow rate up to 1200 l/min (72 m³/h). Head up to 125 metres.

6HR 54/16 - HYD - 1200 litre submersible pump

6HR 54/16 - HYD - 1200 litre submersible pump

Quick View

HYDRAULIC PART. WITHOUT MOTOR.

Flow rate up to 1200 l/min (72 m³/h). Head up to 182 metres.

6HR 54/18 - HYD - 1200 litre submersible pump

6HR 54/18 - HYD - 1200 litre submersible pump

Quick View

HYDRAULIC PART. WITHOUT MOTOR.

Flow rate up to 1200 l/min (72 m³/h). Head up to 205 meters.

Power (HP) Power (HP) 30 Power (HP) 25 Power (HP) -- Power (HP) 40
Pump body Pump body AISI 304 stainless steel Pump body AISI 304 stainless steel Pump body AISI 304 stainless steel Pump body AISI 304 stainless steel
Impeller Impeller AISI 304 stainless steel Impeller AISI 304 stainless steel Impeller AISI 304 stainless steel Impeller AISI 304 stainless steel
Number of impellers Number of impellers 13 Number of impellers 11 Number of impellers 16 Number of impellers 18
Pump shaft Pump shaft AISI 304 stainless steel Pump shaft AISI 304 stainless steel Pump shaft AISI 304 stainless steel Pump shaft AISI 304 stainless steel
Minimum flow rate (l./min.) Minimum flow rate (l./min.) 300 Minimum flow rate (l./min.) 300 Minimum flow rate (l./min.) 300 Minimum flow rate (l./min.) 300
Max. flow rate (l./min.) Max. flow rate (l./min.) 1200 Max. flow rate (l./min.) 1200 Max. flow rate (l./min.) 1200 Max. flow rate (l./min.) 1200
Min. head (m.) Min. head (m.) 68 Min. head (m.) 58 Min. head (m.) 84 Min. head (m.) 95
Max. head (m.) Max. head (m.) 148 Max. head (m.) 125 Max. head (m.) 182 Max. head (m.) 205
Delivery mouth Delivery mouth 3" Delivery mouth 3" Delivery mouth 3" Delivery mouth 3"
Height (cm) Height (cm) 166.9 Height (cm) 145.5 Height (cm) 199 Height (cm) 220.4
External diameter (cm) External diameter (cm) 15 External diameter (cm) 15 External diameter (cm) 15 External diameter (cm) 15
Warranty (years) Warranty (years) 2 Warranty (years) 2 Warranty (years) 2 Warranty (years) 2
