6HR 54/5 - HYD - 1200 litre submersible pump
HYDRAULIC PART. WITHOUT MOTOR.
Flow rate up to 1200 l/min (72 m³/h). Head up to 57 metres.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | Wednesday 21 October - Thursday 22 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | Wednesday 21 October - Thursday 22 October |
 | One Express - 2 giorni Italia | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Thursday 22 October - Monday 26 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | tomorrow |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
Wednesday 21 October - Thursday 22 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
Wednesday 21 October - Thursday 22 October
Carrier: One Express - 2 giorni Italia
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Thursday 22 October - Monday 26 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
tomorrow
The Pedrollo 6HR 54/5 HYD pump consists of only the impeller part, without the motor.
The 6HR 54/5 HYD can be fitted to any 12.5 HP engine.
Recommended for pumping clean water with sand content not exceeding 100 grams per cubic meter.
It has a flow rate that varies from 300 to 1200 litres per minute with a head of 26.5 to 57 metres.
Due to its high performance and reliability, it is suitable for use in the civil, agricultural and industrial fields, for the distribution of water in conjunction with pressure tanks, for irrigation, for pressure raising, for fire-fighting systems.
The pump body is made of micro-cast AISI 304 stainless steel.
Original spare part for 6HR 54/5.
- Power (HP)
- 12.5
- Pump body
- AISI 304 stainless steel
- Impeller
- AISI 304 stainless steel
- Number of impellers
- 5
- Pump shaft
- AISI 304 stainless steel
- Minimum flow rate (l./min.)
- 300
- Max. flow rate (l./min.)
- 1200
- Min. head (m.)
- 26.5
- Max. head (m.)
- 57
- Delivery mouth
- 3"
- Height (cm)
- 81.3
- External diameter (cm)
- 15
- Warranty (years)
- 2
Engine and mechanical performance
- Power (HP)
- 12.5
Pump components and construction
- Pump body
- AISI 304 stainless steel
- Impeller
- AISI 304 stainless steel
- Number of impellers
- 5
- Pump shaft
- AISI 304 stainless steel
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 300
- Max. flow rate (l./min.)
- 1200
- Min. head (m.)
- 26.5
- Max. head (m.)
- 57
Installation and connections
- Delivery mouth
- 3"
Dimensions and weight
- Height (cm)
- 81.3
- External diameter (cm)
- 15
Packaging, maintenance, and warranty
- Warranty (years)
- 2
