TRm 1.3 - 1.75 HP single-phase submersible electric pump with grinder
Flow rate up to 220 l/min (13.2 m³/h). Head up to 23.5 m. 1.3 kW (1.75 HP) motor.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | Thursday 22 October - Friday 23 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | Thursday 22 October - Friday 23 October |
 | One Express - 2 giorni Italia | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Friday 23 October - Monday 26 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Thursday 22 October |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
Thursday 22 October - Friday 23 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
Thursday 22 October - Friday 23 October
Carrier: One Express - 2 giorni Italia
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Friday 23 October - Monday 26 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Thursday 22 October
The TRm 1.3 submersible electric pump from the Tritus series by Pedrollo is the right choice for draining water containing solids or fibres.
Equipped with a high-resistance hardened stainless steel grinder, it is recommended for working on wastewater and wastewater.
Made entirely of cast iron of considerable thickness which gives the electric pump greater strength and resistance to abrasion.
It can be installed up to 10 meters below the water level. For continuous operation, a minimum immersion depth of 300 mm is required.
The TRm 1.3 is the right choice in extreme working conditions.
- Jobs
- drainage, drying up, slightly dirty waters
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 1.3
- Power (HP)
- 1.75
- Absorption at 230V (A)
- 9
- Capacitor
- 25 µF 450 VL
- Pump body
- Cast iron
- Impeller
- Technopolymer
- Number of impellers
- 1
- Crankshaft
- AISI 431 stainless steel
- Check valve
- No
- Minimum flow rate (l./min.)
- 20
- Max. flow rate (l./min.)
- 220
- Min. head (m.)
- 2
- Max. head (m.)
- 23.5
- Max. liquid temperature (°C)
- +40°C
- Cable length (m.)
- 10
- Degree of protection
- IP 68
- Delivery mouth
- 1" 1/4
- Height (cm)
- 40.6
- Weight (Kg)
- 25.5
- Warranty (years)
- 2
Use and formulation of products
- Jobs
- drainage, drying up, slightly dirty waters
Engine and mechanical performance
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 1.3
- Power (HP)
- 1.75
- Absorption at 230V (A)
- 9
- Capacitor
- 25 µF 450 VL
Pump components and construction
- Pump body
- Cast iron
- Impeller
- Technopolymer
- Number of impellers
- 1
- Crankshaft
- AISI 431 stainless steel
- Check valve
- No
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 20
- Max. flow rate (l./min.)
- 220
- Min. head (m.)
- 2
- Max. head (m.)
- 23.5
Liquids and pumping conditions
- Max. liquid temperature (°C)
- +40°C
Power supply and electrical parameters
- Cable length (m.)
- 10
Safety and protection
- Degree of protection
- IP 68
Installation and connections
- Delivery mouth
- 1" 1/4
Dimensions and weight
- Height (cm)
- 40.6
- Weight (Kg)
- 25.5
Packaging, maintenance, and warranty
- Warranty (years)
- 2
|
|
|
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Related Products
-
- -42%
€77.84 tax incl. €134.20
Reviews (1) - Review moderation
Compare with Similar Products
 TRm 1.3 - 1.75 HP single-phase submersible electric pump with grinderThis product Flow rate up to 220 l/min (13.2 m³/h). Head up to 23.5 m. 1.3 kW (1.75 HP) motor. |  TRm 1.1 - 1.5 HP single-phase submersible electric pump with grinder Flow rate up to 140 l/min (7.2 m³/h). Head up to 23 m. 1.1 kW (1.5 HP) motor. |  TRm 1.5 - 2 HP single-phase submersible electric pump with grinder Flow rate up to 270 l/min (12 m³/h). Head up to 26 m. 1.5 kW (2 HP) motor. |  TRm 2.2 AP - 3 HP single-phase submersible electric pump with grinder Flow rate up to 275 l/min (16.5 m³/h). Head up to 36.5 m. 2.2 Kw (3 HP) motor. | |
|---|---|---|---|---|
| Price | Price €1,281.00 -45% €704.55 | Price €1,255.38 -45% €690.46 | Price €2,088.64 -45% €1,148.75 | Price €2,690.10 -45% €1,479.56 |
| Jobs | Jobs drainage, drying up, slightly dirty waters | Jobs drainage, drying up, slightly dirty waters | Jobs slightly dirty waters | Jobs slightly dirty waters, drainage, drying up |
| Motor connection | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE | Motor connection SINGLE-PHASE |
| Power (Kw) | Power (Kw) 1.3 | Power (Kw) 1.1 | Power (Kw) 1.5 | Power (Kw) 2.2 |
| Power (HP) | Power (HP) 1.75 | Power (HP) 1.5 | Power (HP) 2 | Power (HP) 3 |
| Absorption at 230V (A) | Absorption at 230V (A) 9 | Absorption at 230V (A) 7.4 | Absorption at 230V (A) 10 | Absorption at 230V (A) 14.0 |
| Capacitor | Capacitor 25 µF 450 VL | Capacitor 25 µF 450 VL | Capacitor 50 µF 450 VL | Capacitor -- |
| Pump body | Pump body Cast iron | Pump body Cast iron | Pump body Cast iron | Pump body Cast iron |
| Impeller | Impeller Technopolymer | Impeller Technopolymer | Impeller AISI 304 stainless steel | Impeller AISI 304 stainless steel |
| Number of impellers | Number of impellers 1 | Number of impellers 1 | Number of impellers 1 | Number of impellers 1 |
| Crankshaft | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel | Crankshaft AISI 431 stainless steel |
| Check valve | Check valve No | Check valve No | Check valve No | Check valve No |
| Minimum flow rate (l./min.) | Minimum flow rate (l./min.) 20 | Minimum flow rate (l./min.) 20 | Minimum flow rate (l./min.) 20 | Minimum flow rate (l./min.) 20 |
| Max. flow rate (l./min.) | Max. flow rate (l./min.) 220 | Max. flow rate (l./min.) 140 | Max. flow rate (l./min.) 270 | Max. flow rate (l./min.) 400 |
| Min. head (m.) | Min. head (m.) 2 | Min. head (m.) 2 | Min. head (m.) 2 | Min. head (m.) 2 |
| Max. head (m.) | Max. head (m.) 23.5 | Max. head (m.) 23 | Max. head (m.) 26 | Max. head (m.) 34.5 |
| Max. liquid temperature (°C) | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C | Max. liquid temperature (°C) +40°C |
| Cable length (m.) | Cable length (m.) 10 | Cable length (m.) 10 | Cable length (m.) 10 | Cable length (m.) 10 |
| Degree of protection | Degree of protection IP 68 | Degree of protection IP 68 | Degree of protection IP 68 | Degree of protection IP 68 |
| Delivery mouth | Delivery mouth 1" 1/4 | Delivery mouth 1" 1/4 | Delivery mouth 1/2" | Delivery mouth 1" 1/2 |
| Height (cm) | Height (cm) 40.6 | Height (cm) 40.6 | Height (cm) 48.9 | Height (cm) 48.0 |
| Width (cm) | Width (cm) -- | Width (cm) -- | Width (cm) -- | Width (cm) 25.6 |
| Depth (cm) | Depth (cm) -- | Depth (cm) -- | Depth (cm) -- | Depth (cm) 32.9 |
| Weight (Kg) | Weight (Kg) 25.5 | Weight (Kg) 25.7 | Weight (Kg) 45.5 | Weight (Kg) 53 |
| Warranty (years) | Warranty (years) 2 | Warranty (years) 2 | Warranty (years) 2 | Warranty (years) 2 |
