100-DV-9V - 1" solenoid valve
Female/female connection. Without flow regulator. Bistable solenoid.
The Rain Bird 100-DV 9V Solenoid Valve is designed for use in small residential and commercial landscape irrigation systems.
The reverse flow design prevents flooding, while the dual filter system on the solenoid valve reduces clogging due to debris.
The 100-DV 9V solenoid valve features an efficient, low-energy encapsulated solenoid with built-in plunger and a 200 micron filter.
The heavy-duty solenoid resists breakage from drops and resists electrical shock with 24 VAC protection.
The elliptical filter, with which it is equipped, is 60% more efficient in preventing obstructions from debris than other solenoid valves.
Flow control is ideal for applications with variable pressure.
Manual ON/OFF control is achieved by turning the solenoid a quarter turn. Equipped with an atmospheric venting device that allows the system to be flushed of suspended matter.
The 100-DV 9V solenoid valve is not only very durable but also very simple to install.
- Max. flow rate (l./min.)
- Max. working pressure (bar)
- Manual flow regulation
- No
- Self-cleaning device
- No
- Supply voltage (Volts)
- 9
- Height (cm)
- 11.4
- Width (cm)
- 8.4
- Depth (cm)
- 11.1
- Attack size
- 1 "
- Warranty (years)
- 2
- Type of attack
- female/female
- Thread
- NPT
- Body
- PVC
Reviews (1) - Review moderation
Compare with Similar Products
 100-DV-9V - 1" solenoid valveThis product Female/female connection. Without flow regulator. Bistable solenoid. |  PGV-100-G-B-DC - 1" Solenoid Valve Female/female connection. Without flow regulator. Bistable solenoid. | |
|---|---|---|
| Price | Price €82.95 -40% €49.77 | Price €32.60 -5% €30.97 |
| Max. flow rate (l./min.) | Max. flow rate (l./min.) -- | Max. flow rate (l./min.) -- |
| Max. working pressure (bar) | Max. working pressure (bar) -- | Max. working pressure (bar) -- |
| Manual flow regulation | Manual flow regulation No | Manual flow regulation Yes |
| Self-cleaning device | Self-cleaning device No | Self-cleaning device No |
| Supply voltage (Volts) | Supply voltage (Volts) 9 | Supply voltage (Volts) 9 |
| Height (cm) | Height (cm) 11.4 | Height (cm) 13 |
| Width (cm) | Width (cm) 8.4 | Width (cm) 6 |
| Depth (cm) | Depth (cm) 11.1 | Depth (cm) -- |
| Attack size | Attack size 1 " | Attack size 1 " |
| Warranty (years) | Warranty (years) 2 | Warranty (years) 2 |
| Type of attack | Type of attack female/female | Type of attack female/female |
| Thread | Thread NPT | Thread NPT |
| Body | Body PVC | Body PVC |
