GP2Wm - FCR 100/5 - Single-phase pressure group 2x1.25 HP
2 single-phase electric pumps.
2 x 0.90 kW (2 x 1.25 HP) motors. Flow rate up to 250 l/min (15 m³/h). Head up to 63 m.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | Tuesday 20 October - Wednesday 21 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | Tuesday 20 October - Wednesday 21 October |
 | One Express - 2 giorni Italia | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Wednesday 21 October - Monday 26 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Tuesday 20 October |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
Tuesday 20 October - Wednesday 21 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
Tuesday 20 October - Wednesday 21 October
Carrier: One Express - 2 giorni Italia
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Wednesday 21 October - Monday 26 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Tuesday 20 October
The GP2Wm - FCR 80/5 pressure group consists of two FCRm 100/5 pumps controlled by an MT12 inverter which allows each pump to operate at variable speed and constant pressure.
The type of inverter used, mounted directly on the pump delivery, is dedicated to the control of electric pumps.
The inverter has an internal pressure transducer for maintaining pressure regulation. Flow control therefore stops the pump when there is no water demand from the user, also protecting the pump from depriming in the absence of water.
The unit is supplied with the pressure, absorption and rotation parameters already set, the pressure parameter can be easily changed even after installation.
The operating flow rate is achieved by the simultaneous operation of the two pumps. During periods of low consumption, operation is limited to one pump. Vertical pumps are chosen for their exceptionally quiet operation and high efficiency.
The units are hydraulically and electrically pre-assembled on a frame and include shut-off ball valves with union and ONDASTOP silent diaphragm check valves.
The delivery groups can be combined with a membrane tank, which acts as a water hammer arrester.
Supplied in versions with single-phase 230 volt or three-phase 380 volt power supply.
All our pump units are designed to meet the specific needs of the system, so it is possible to create units with a single pump or with flow rate/head characteristics different from those shown in the table.
- Jobs
- water supply, domestic, pressurization systems, irrigation
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 1.8
- Power (HP)
- 2.5
- Absorption at 230V (A)
- 2 x 9.5
- Minimum flow rate (l./min.)
- 5
- Max. flow rate (l./min.)
- 250
- Min. head (m.)
- 8
- Max. head (m.)
- 63
- Suction mouth
- 2"
- Delivery mouth
- 1" 1/2
- Height (cm)
- 73.4
- Width (cm)
- 53.0
- Depth (cm)
- 56.3
- Weight (Kg)
- 54
- Warranty (years)
- 2
Use and formulation of products
- Jobs
- water supply, pressurization systems, irrigation, domestic
Engine and mechanical performance
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 1.8
- Power (HP)
- 2.5
- Absorption at 230V (A)
- 2 x 9.5
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 5
- Max. flow rate (l./min.)
- 250
- Min. head (m.)
- 8
- Max. head (m.)
- 63
Installation and connections
- Suction mouth
- 2"
- Delivery mouth
- 1" 1/2
Dimensions and weight
- Height (cm)
- 73.4
- Width (cm)
- 53.0
- Depth (cm)
- 56.3
- Weight (Kg)
- 54
Packaging, maintenance, and warranty
- Warranty (years)
- 2
