FN-24 KU - 24 mm mechanical seal

The Pedrollo FN-24 KU mechanical seal is mainly used in medium and large Pedrollo surface electric pumps.

It has a reduced installation length and is standardised according to EN 12756.

Suitable for electric pumps with a 24 mm crankshaft.

The FN-24 KU mechanical seal is mainly used on FCR and HT pumps.

The mechanical seal's job is to keep the hydraulic part separate from the electrical part. It prevents water from reaching the bearings and motor.

The FN-24 KU seal allows shaft rotation without using a rigid seal.

The seal consists of two parts: a rotating one and a fixed one. Made of graphite, ceramic, NBR, and AISI 316L stainless steel.

The seal inside the electric pump is one of the most stressed parts and is therefore subject to wear. It's important to replace it when water is found in the motor.

Original spare part for model FCR 15/2, FCR 15/3, FCR 15/4, FCR 15/5, FCR 30/2, FCR 30/3, FCR 30/4, HT 15/2, HT 15/2R, HT 15/3, HT 15/3R, HT 15/4, HT 15/5, HT 30/2, HT 30/2R, HT 30/3, HT 30/4, HT 15/2 - PRO, HT 15/2R - PRO, HT 15/3 - PRO, HT 15/3R - PRO, HT 15/4 - PRO, HT 15/5 - PRO, HT 30/2 - PRO, HT 30/2R - PRO, HT 30/3 - PRO, HT 30/4 - PRO.
