TOP 3 (10m) - 0.75 HP clear water drainage pump Pedrollo - 1
zoom_out_map
chevron_left chevron_right
-42%

TOP 3 (10m) - 0.75 HP clear water drainage pump

Flow rate up to 260 l/min (15.6 m³/h). Head up to 10.4 m. 0.55 Kw (0.75 HP) motor. 10 meters of cable with shuko plug.

€153.55 Tax included

€125.86 Tax excluded

€264.74-42%

Variants:
TOP 1 (10m) - Elettropompa da drenaggio per acque chiare da 0.33 HP
TOP 2 (10m) - Elettropompa da drenaggio per acque chiare da 0.50 HP
TOP 3 (10m) - Elettropompa da drenaggio per acque chiare da 0.75 HP
TOP 4 - Elettropompa da drenaggio per acque chiare da 1 HP
TOP 5 - Elettropompa da drenaggio per acque chiare da 1.25 HP
There are no reviews yet
Close
Make a purchase proposal

Your Offer is sent.

Your Offer is accepted, please check your inbox.

TOP 3 (10m) - 0.75 HP clear water drainage pump
  • Use dot instead of comma

Loading

Telephone support for information before purchasing.
Reinforced packaging to reduce transport damage.
After-sales assistance for product installation.
We supply all spare parts on this product.
Description

The TOP series is suitable for the drainage of clear water without abrasive particles.

The construction solutions employed guarantee ease of use and operational safety thanks to the total cooling of the motor and the double seal on the shaft.

They are recommended for emergency drainage of small flooded areas (rooms, basements, garages), disposal of used domestic water (dishwashers, washing machines), emptying collection pits.

Data sheet
Pedrollo
TOP 3 10MT
10 Items
Motor connection
SINGLE PHASE
Power (Kw)
0.55
Power (HP)
0.75
Absorption at 230V (A)
3.2
Capacitor
14 µF450 VL
Delivery port
1 "1/4
Body Pump
Technopolymer
Impeller
Noryl
Number of impellers
1
Motor shaft
AISI 431 stainless steel
Check valve
no
Degree of protection
IP 68
Flow rate min. (l./min.)
20
Max flow (l./min.)
260
Min head (m.)
2
Max head (m.)
10.5
Cable length (m)
10
Employments
drainage, drying up
Liquid temperature max. (° C)
40
Height (cm)
28.7
Width (cm)
15.2
Weight kg)
6.6
Guarantee
2
Attachments

TOP technical sheet

Construction and operating characteristics. Working curves, limits of use and dimensions of the Pedrollo TOP series pumps.

file_download Download (2.2MB)

Buy it with

  • TOP 3 (10m) - 0.75 HP clear water drainage pump
  • +
  • TOP 2 (5m) - 0.50 HP clear water drainage electric pump
  • €273.84-10 %
    Total price: €246.46
TOP models and performances
GUY
single phase
TOP 1
TOP 2
TOP 3
TOP 4
TOP 5
POWER
KWHP
0.250.33
0.370.50
0.550.75
0.751
0.921.25
Construction data of the TOP series
TOP pump cutaway
Bearings
Pump side motor bearing6201 ZZ
Opposite side engine bearing6201 ZZ
Tree holding
Type of sealDouble Seal: Mechanical and Lip with oil chamber
Engine side modelLip seal
LM diameter12
LM elastomerNBR
Shrinkage DN1=450 DN2=350STA-12R
LP diameter12
LP fixed ringCeramic
LP rotating ringGraphite
LP elastomerNBR
Materials
1.0 - Pump bodyReinforced technopolymer
2.2 - Suction coverStainless steel EN 1.4301 (AISI 304)
3.0 - ImpellerReinforced technopolymer
4.0 - Pump shaftStainless steel EN 1.4057 (AISI 431)
5.1 - DiffuserReinforced technopolymer
6.0 - Motor holderStainless steel EN 1.4301 (AISI 304)
6.1 - Engine coverStainless steel EN 1.4301 (AISI 304)
8.0 - Suction Grid/FilterReinforced technopolymer
