6SR18/18 - PD - 20 HP three-phase submersible electric pump

Name: 6SR18/18 - PD - 20 HP three-phase submersible electric pump
Brand: Pedrollo
SKU: 6SR18/18 - PD
Price: 1735.88 EUR
Availability: InStock

Flow rate up to 450 l/min (27 m³/h). Head up to 244 m. 15 Kw (20 HP) motor.

Variants:

Order it before 23:59 of Thursday and receive it tomorrow with SDA - 2 giorni Italia

Delivery Options

	Description	Estimated Delivery
Mail Boxes - 2 giorni	This courier delivers within 48 hours from the moment we entrust the products to him.	Wednesday 11 June - Thursday 12 June
Poste Italiane - 2 giorni Italia	This courier delivers within 24/48 hours from the moment we entrust them with the products.	Wednesday 11 June - Thursday 12 June
One Express - 2 giorni Italia	This courier delivers within 24/72 hours from the moment we entrust them with the products.	Friday 13 June - Tuesday 17 June
SDA - 2 giorni Italia	2 DAYS	tomorrow

Carrier: Mail Boxes - 2 giorni

Description: This courier delivers within 48 hours from the moment we entrust the products to him.

Estimated delivery:
Wednesday 11 June - Thursday 12 June

Carrier: Poste Italiane - 2 giorni Italia

Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.

Estimated delivery:
Wednesday 11 June - Thursday 12 June

Carrier: One Express - 2 giorni Italia

Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.

Estimated delivery:
Friday 13 June - Tuesday 17 June

Carrier: SDA - 2 giorni Italia

Description: 2 DAYS

Estimated delivery:
tomorrow

✖

Make a purchase proposal

Telephone support for information before purchasing.

Reinforced packaging to reduce transport damage.

After-sales assistance for product installation.

We supply all spare parts on this product.

Description

The PEDROLLO 6SR18/15 submersible electric pump is recommended for pumping clean water with a sand content not exceeding 100 grams per cubic metre.

The PEDROLLO 6SR18/15 has a flow rate that varies from 50 to 450 litres per minute with a head from 96 to 244 metres.

Due to its high performance and reliability, it is suitable for use in the civil, industrial and agricultural fields, for the distribution of water in conjunction with pressure tanks, for irrigation, for washing systems, for pressure raising or for fire-fighting systems.

Data sheet

Motor connection: THREE-PHASE
Power (Kw): 15
Power (HP): 20
Delivery mouth: 3 "
Pump body: Cast iron
Impeller: Noryl
Number of impellers: 18
Pump shaft: AISI 304 stainless steel
Min. flow rate (l./min.): 50
Max. flow rate (l./min.): 450
Min. head (m.): 96
Max. head (m.): 244
Jobs: water supply, pressurization systems, irrigation, fire prevention systems
Max. liquid temperature (°C): 35
Height (cm): 201.8
External diameter (cm): 149.5
Weight (Kg): 87.6
Warranty (years): 2

Attachments

6SR data sheet

Performance, working curves and limits of use of the 6-inch submersible electric pumps of the 6SR series by Pedrollo.

Download (3.88MB)

6SR 18 models and performance

GUY

three-phase

6SR 18/4

6SR 18/6

6SR 18/9

6SR 18/11

6SR 18/13

6SR 18/15

6SR 18/18

6SR 18/22

6SR 18/26

POWER
KW	HP
4	5.5
5.5	7.5
7.5	10
9.2	12.5
11	15
13	17.5
15	20
18.5	25
22	30

IMPELLERS
number
4
6
9
11
13
15
18
22
26

PERFORMANCE
Q litres/min	H meters
50 ÷ 450	54 ÷ 22
50 ÷ 450	81 ÷ 32
50 ÷ 450	122 ÷ 48
50 ÷ 450	149 ÷ 59
50 ÷ 450	176 ÷ 70
50 ÷ 450	203 ÷ 80
50 ÷ 450	244 ÷ 96
50 ÷ 450	298 ÷ 118
50 ÷ 450	352 ÷ 139

MOUTH
DN
3"

Q	m³/hour	0	3	6	9	12	15	18	21	24	27
Q	l/min	0	50	100	150	200	250	300	350	400	450
H	meters	54	53.8	53	51	49	46	42	37	30	22
		81	80.5	79	77	74	69	63	55	45	32
		122	121	119	116	111	103	94	83	68	48
		149	148	145.5	141	135	126	115	101	83	59
		176	175	172	167	160	149	136	120	98	70
		203	202	199	193	185	172	157	138	113	80
		244	242	238	231	221	206	188	165	135	96
		298	296	291	282	270	252	230	202	165	118
		352	350	344	334	320	298	272	239	195	139

Construction data of the 6SR series

Bearings

Pump bearing - fixed part	Special elastomer
Pump bearing - rotating part	Sintered AISI 316 steel with ceramic coating

Tree holding

Materials

1.3 - Delivery body	Cast iron GJL 200 EN 1561
3.0 - Impeller	Reinforced technopolymer
4.0 - Pump shaft	Stainless steel EN 1.4301 (AISI 304)
4.2 - Towing joint	Stainless steel EN 1.4021 (AISI 420)
5.0 - Stadium box	Stainless steel EN 1.4301 (AISI 304)
5.1 - Diffuser	Reinforced technopolymer
7.0 - Lantern	Cast iron GJL 200 EN 1561
7.1 - Check Valve	Stainless steel EN 1.4301 (AISI 304)
7.2 - Pump shirt	Stainless steel EN 1.4301 (AISI 304)
7.3 - Cable cover	Stainless steel EN 1.4301 (AISI 304)
8.0 - Suction Grid/Filter	Stainless steel EN 1.4301 (AISI 304)
