VSP2m-MK 3/6 - Single-phase pressure group 2x2 HP
2 single-phase electric pumps.
2 x 1.5 kW (2 x 2 HP) motor. Flow rate up to 160 l/min (9.6 m³/h). Head up to 99 m.
Delivery Options
| Carrier | Description | Estimated Delivery | |
|---|---|---|---|
 | Mail Boxes - 2 giorni | This courier delivers within 48 hours from the moment we entrust the products to him. | tomorrow - Friday 16 October |
 | Poste Italiane - 2 giorni Italia | This courier delivers within 24/48 hours from the moment we entrust them with the products. | tomorrow - Friday 16 October |
 | One Express - 2 giorni Italia | This courier delivers within 24/72 hours from the moment we entrust them with the products. | Friday 16 October - Monday 19 October |
 | Poste Italiane - 3 giorni punto di ritiro | This courier delivers within 24/72 hours from the moment we entrust them with the products. | tomorrow |
Carrier: Mail Boxes - 2 giorni
Description: This courier delivers within 48 hours from the moment we entrust the products to him.
Estimated delivery:
tomorrow - Friday 16 October
Carrier: Poste Italiane - 2 giorni Italia
Description: This courier delivers within 24/48 hours from the moment we entrust them with the products.
Estimated delivery:
tomorrow - Friday 16 October
Carrier: One Express - 2 giorni Italia
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
Friday 16 October - Monday 19 October
Carrier: Poste Italiane - 3 giorni punto di ritiro
Description: This courier delivers within 24/72 hours from the moment we entrust them with the products.
Estimated delivery:
tomorrow
The VSP2m-MK 3/6 system from Pedrollo 's VSP2 series is recommended for water supply activities and for the movement of clean water.
The group is composed of two MKm 3/6 electric pumps connected in parallel with integrated inverter devices.
It allows the system pressure to be kept constant even in the event of drops.
When the pressure in the system drops due to water withdrawal, the first VSP unit starts up to maintain constant pressure and when maximum speed is reached the second one also starts up.
The VSP2m-MK 3/6 system protects the system against dry running, overvoltage, undervoltage and overtemperature.
The unit is extremely silent as it is installed on a base made of metal profile equipped with adjustable anti-vibration feet.
- Jobs
- water supply, pressurization systems, irrigation
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 3
- Power (HP)
- 4
- Minimum flow rate (l./min.)
- 5
- Max. flow rate (l./min.)
- 160
- Min. head (m.)
- 58
- Max. head (m.)
- 99
- Suction mouth
- 2"
- Delivery mouth
- 1" 1/2
- Height (cm)
- 86.3
- Width (cm)
- 53.0
- Depth (cm)
- 55.5
- Weight (Kg)
- 83
- Warranty (years)
- 2
Use and formulation of products
- Jobs
- water supply, pressurization systems, irrigation
Engine and mechanical performance
- Motor connection
- SINGLE-PHASE
- Power (Kw)
- 3
- Power (HP)
- 4
Hydraulic performance and filtration
- Minimum flow rate (l./min.)
- 5
- Max. flow rate (l./min.)
- 160
- Min. head (m.)
- 58
- Max. head (m.)
- 99
Installation and connections
- Suction mouth
- 2"
- Delivery mouth
- 1" 1/2
Dimensions and weight
- Height (cm)
- 86.3
- Width (cm)
- 53.0
- Depth (cm)
- 55.5
- Weight (Kg)
- 83
Packaging, maintenance, and warranty
- Warranty (years)
- 2
