QEM 300 - Electrical panel for 3 HP single-phase electric pump
For starting one 4" submersible electric pump. Power: 2.2 kW (3 HP). Manual operation. Overload protection. Capacitor.
The QEM 100 control panel from Pedrollo 's QEM series is compatible with 3-inch submersible well pumps.
It is suitable for any system for the collection of groundwater for domestic and residential use.
The QEM 100 electrical panel starts the electric pump via the main switch, while the thermal circuit breaker stops the motor in the event of a current overload.
It can boast of the IP55 protection degree.
Installation is simple and use is intuitive thanks to the various lights and LED indicators.
- Power (HP)
- 3
- Capacitor
- 75 µF 450 VL
- Degree of protection
- IP 55
- LCD display
- No
- Line power supply
- single-phase
- Supply voltage (Volts)
- 230
- Engine power supply
- single phase
- Motor Phase Current (Amperes)
- 18
- Overcurrent protection
- Yes, thermal circuit breaker
- Amperometric protection
- No
- Short circuit protection
- No
- Dry running protection
- No
- Height (cm)
- 20.2
- Width (cm)
- 15
- Depth (cm)
- 10.6
- Weight (Kg)
- 0.91
- Warranty (years)
- 2
|
|
|
| ||||||||||||||||||||||||||||||||||||||||
